İŞLEMCİ : Supports 6th/7th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
YONGA SETİ : Intel® B250 Chipset
BELLEK : • 2 x DDR4 memory slots, support up to 32GB - 7th Gen processors support DDR4 2400/ 2133 MHz* - 6th Gen processors support DDR4 2133 MHz* • Dual channel memory architecture • Supports non-ECC, un-buffered memory • Supports Intel® Extreme Memory Profile (XMP)
DAHİLİ GRAFİK : • 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz • 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
GENİŞLEME YUVALARI : • 1 x PCIe 3.0 x16 slots • 2 x PCIe 3.0 x1 slots
SES DESTEĞİ : • Realtek® ALC887 Codec - 7.1-Channel High Definition Audio
LAN : • 1 x Realtek® RTL8111H Gigabit LAN controller
USB PORTLARI : • Intel® B250 Chipset - 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector) - 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
DEPOLAMA ARAYÜZÜ : • Intel® B250 Chipset • 6 x SATA 6Gb/s ports • 1 x M.2 slots (Key M)* - Support up to PCIe 3.0 x4 and SATA 6Gb/ - Supports 2242/ 2260/ 2280 storage devices - Intel® Optane™ Memory Ready - Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host card**
ARKA GİRİŞ/ÇIKIŞ PORTLARI : - 1 x PS/2 keyborard/ mouse combo port - 2 x USB 2.0 ports - 1 x DVI-D port - 1 x VGA port - 1 x LAN (RJ45) port - 4 x USB 3.1 Gen1 ports - 3 x audio jacks
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : - 1 x 24-pin ATX main power connector - 1 x 8-pin ATX 12V power connector - 6 x SATA 6Gb/s connectors - 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) - 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) - 1 x 4-pin CPU fan connector - 1 x 4-pin system fan connector - 1 x Front panel audio connector - 2 x Front panel connectors - 1 x Chassis Intrusion connector - 1 x Serial Port connector - 1 x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : -
FORM FAKTÖRÜ : • 8.9 in. x 7.3 in. (22.6 cm x 18.5 cm) • Micro-ATX Form Factor
BIOS : -
AÇIKLAMA : -
