İŞLEMCİ : Supports Intel® Core™ X-Series Processor Family for LGA2066 Socket
YONGA SETİ : Intel® X299 Chipset
BELLEK : • 8 x DDR4 memory slots, support up to 128GB • Quad channel memory architecture with the CPU that supports up to 4-channels DDR4** - X-series processor support DDR4 4133+(OC)/ 4000(OC)/ 3866(OC)/ 3800(OC) /3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/ 2933(OC)/ 2800(OC)/ 2667/ 2400/ 2133 MHz* • Dual channel memory architecture with the CPU that supports up to 2-channels DDR4** - X-series processor support DDR4 4500+(OC)/ 4400(OC)/ 4333(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/ 2933(OC)/ 2800(OC)/ 2667/ 2400/ 2133 MHz* • Supports Intel® Extreme Memory Profile (XMP)
DAHİLİ GRAFİK : Yok
GENİŞLEME YUVALARI : • 4 x PCIe 3.0 x16 slots - Support x16/x16/x8 mode with the 44-lane CPU.* - Support x16/x8/x4 modes with the 28-lane CPU.* - Support x8/x8/x0, x8/x4/x4 modes with the 16-lane CPU.* • 2 x PCIe 3.0 x1 slots
SES DESTEĞİ : • Realtek® ALC1220 Codec - 7.1-Channel High Definition Audio - Supports S/PDIF output
LAN : • 1 x Intel® I219-V Gigabit LAN controller • 1 x Intel® I211 Gigabit LAN controller
USB PORTLARI : • ASMedia® ASM3142 Chipset - 3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel, 1 Type-C port available through the internal USB connector) • ASMedia® ASM1074 Hub - 3 x USB 3.1 Gen1 (SuperSpeed USB) ports on the back panel • Intel® X299 Chipset - 5 x USB 3.1 Gen1 (SuperSpeed USB) ports (1 Type-A port on the back panel, 4 ports available through the internal USB connectors) - 8 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
DEPOLAMA ARAYÜZÜ : • Intel® X299 Chipset • 8 x SATA 6Gb/s ports* • 2 x M.2 slot (Key M) - Supports up to PCIe 3.0 x4 and SATA 6Gb/s - M2_1 slot supports 2242/ 2260 /2280 storage devices - M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices - Supports Intel® Optane™ Memory Ready for all M.2 slots • 1 x U.2 port *** - Supports PCIe 3.0 x4 NVMe storage • Supports Intel® Smart Response Technology for Intel Core™ processors
ARKA GİRİŞ/ÇIKIŞ PORTLARI : - 1 x Clear CMOS button - 1 x BIOS FLSAHBACK+ button - 1 x PS/2 keyboard/ mouse combo port - 1 x BIOS FLASHBACK+ port - 4 x USB 2.0 Type-A ports - 1 x BIOS FLASHBACK+ port - 4 x USB 3.1 Gen1 Type-A ports - 2 x LAN (RJ45) ports - 1 x USB 3.1 Gen2 Type-A port - 1 x USB 3.1 Gen2 Type-C port - 5 x OFC audio jacks - 1 x Optical S/PDIF OUT connector
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : - 1 x 24-pin ATX main power connector - 1 x 8-pin ATX 12V power connector - 8 x SATA 6Gb/s connectors - 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) - 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) - 1 x USB 3.1 Gen2 Type-C port - 1 x 4-pin CPU fan connector - 1 x 4-pin Water Pump connector - 4 x 4-pin system fan connectors - 2 x Front panel connectors - 1 x Front panel audio connector - 1 x RGB LED connector - 1 x TPM module connector - 1 x Virtual RAID on CPU connector - 1 x Thunderbolt add-on card connector
İŞLETİM SİSTEMİ DESTEĞİ : -
FORM FAKTÖRÜ : • 12 in. x 9.6 in. (30.5 cm x 24.3 cm) • ATX Form Factor
BIOS : -
AÇIKLAMA : -
