İŞLEMCİ : Supports 6th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
YONGA SETİ : Intel® H110 Chipset
BELLEK : • 2 x DDR4 memory slots, support up to 32GB - Supports DDR4 2133 MHz • Dual channel memory architecture • Supports Non-ECC, un-buffered memory • Supports Intel® Extreme Memory Profile (XMP)
DAHİLİ GRAFİK : • 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
GENİŞLEME YUVALARI : • 1 x PCIe 3.0 x16 slot • 2 x PCIe 2.0 x1 slots
SES DESTEĞİ : • Realtek® ALC887 Codec • 7.1-Channel High Definition Audio
LAN : • 1 x Realtek RTL8111H Gigabit LAN controller
USB PORTLARI : • Intel® H110 Chipset - 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connector) - 6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connectors)
DEPOLAMA ARAYÜZÜ : • Intel® H110 Chipset • 4 x SATA 6Gb/s ports
ARKA GİRİŞ/ÇIKIŞ PORTLARI : - 1 x PS/2 keyboard/ mouse port - 4 x USB 2.0 ports - 2 x USB 3.1 Gen1 ports - 1 x DVI-D port - 1 x LAN (RJ45) port - 3 x audio jacks
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : - 1 x 24-pin ATX main power connector - 1 x 4-pin ATX 12V power connector - 4 x SATA 6Gb/s connectors - 1 x USB 2.0 connectors (supports additional 2 USB 2.0 ports) - 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) - 1 x 4-pin CPU fan connector - 1 x 4-pin system fan connectors - 1 x Front panel audio connector - 2 x Front panel connectors - 1 x TPM module connector - 1 x Serial Port connector - 1 x Chassis Intrusion connector - 1 x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : -
FORM FAKTÖRÜ : • 9.3 in. x 7.1 in. (23.5 cm x 18.0 cm) Micro-ATX Form Factor
BIOS : -
AÇIKLAMA : -
