İŞLEMCİ : Supports 6th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
YONGA SETİ : Intel® H110 Chipset
BELLEK : 2x DDR4 memory slots, support up to 32GB Supports DDR4 2133 MHz* Dual channel memory architecture Supports non-ECC, un-buffered memory
DAHİLİ GRAFİK : 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
GENİŞLEME YUVALARI : 1 x PCIe 3.0 x16 slot 1 x PCIe 2.0 x1 slot 2 x PCIe slots
SES DESTEĞİ : Realtek® ALC887 Codec 7.1-Channel High Definition Audio
LAN : 1 x Realtek RTL8111H Gigabit LAN controller
USB PORTLARI : Intel® H110 Chipset - 4x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connector) - 6x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connectors) GENESYS GL850G Chipset - 2x USB 2.0 (High-speed USB) ports through the internal USB connectors
DEPOLAMA ARAYÜZÜ : On-Board 4 x SATA 6Gb/s ports
ARKA GİRİŞ/ÇIKIŞ PORTLARI : - 1x PS/2 mouse & keyboard combo port - 1 x VGA port - 1 x DVI-D port - 1 x COM port - 2 x USB 3.1 Gen1 ports - 4 x USB 2.0 ports - 1 x LAN (RJ45) port - 3 x audio jacks
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : - 1x 24-pin ATX main power connector - 1x 8-pin ATX 12V power connector - 4x SATA 6Gb/s connectors - 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) - 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) - 1x 4-pin CPU fan connector - 2x 4-pin system fan connectors - 1x Front panel audio connector - 2x Front panel connectors - 1x Serial Port connector - 1x Parallel Port connector - 1x TPM connector - 1x Chassis Intrusion connector - 1x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : -
FORM FAKTÖRÜ : Micro-ATX Form Factor
BIOS : -
AÇIKLAMA : 8.07 in. x 9.6 in. (20.5 cm x 24.4 cm)
