İŞLEMCİ : Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
YONGA SETİ : Intel® H310 Chipset
BELLEK : 2 x DDR4 memory slots, support up to 32GB Supports DDR4 2666/ 2400/ 2133 MHz (by JEDEC) Supports DDR4 2666/ 2400/ 2133 MHz (by XMP OC) Supports Dual-Channel modee Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP)
DAHİLİ GRAFİK : 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
GENİŞLEME YUVALARI : 1 x PCIe 3.0 x16 slot 2 x PCIe 2.0 x1 slots
SES DESTEĞİ : 7.1-Channel High Definition Audio
LAN : 1 x Realtek RTL8111H Gigabit LAN controller
USB PORTLARI : 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector) 6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
DEPOLAMA ARAYÜZÜ : 4 x SATA 6Gb/s ports
ARKA GİRİŞ/ÇIKIŞ PORTLARI : PS/2 Combo Port DVI-D Port USB 3.1 Gen1 LAN Port HD Audio Connectors USB 2.0 Port USB 2.0 Port
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 2 x Front panel connectors 1 x Front panel audio connector 1 x Serial port connector 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : Support for Windows® 10 64-bit
FORM FAKTÖRÜ : m-ATX Form Factor
BIOS : -
AÇIKLAMA : Dimensions : 8.9 in. x 6.9 in. (22.6 cm x 17.5 cm)
