İŞLEMCİ : Supports 9th/8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
YONGA SETİ : Intel® B365 Chipset
BELLEK : 2x DDR4 memory slots, support up to 32GB Supports DDR4 2666/ 2400/ 2133 MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP)
DAHİLİ GRAFİK : 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz 1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz
GENİŞLEME YUVALARI : 1 x PCIe 3.0 x16 slots 2 x PCIe 3.0 x1 slots
SES DESTEĞİ : 7.1-Channel High Definition Audio
LAN : 1 x Realtek RTL8111H Gigabit LAN controller
USB PORTLARI : 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector) 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
DEPOLAMA ARAYÜZÜ : 6 x SATA 6Gb/s ports 1 x M.2 slot (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices Intel® Optane™ Memory Ready
ARKA GİRİŞ/ÇIKIŞ PORTLARI : PS/2 Combo VGA Port LAN Port HD Audio Connectors USB 2.0 Ports HDMI Port USB 3.1 Gen1 Ports
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x USB 3.1 Gen1 connector1 (supports additional 2 USB 3.1 Gen1 ports) 6 x SATA 6Gb/s connectors 1 x Clear CMOS jumper 2 x Front panel connectors 1 x Serial port connector 1 x Chassis Intrusion connector 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x Front panel audio connector 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x TPM module connector
İŞLETİM SİSTEMİ DESTEĞİ : Support for Windows® 10 64-bit
FORM FAKTÖRÜ : Micro-ATX Form Factor
BIOS : -
AÇIKLAMA : 8.9 in. x 7.3 in. (22.6 cm x 18.5 cm) 6 mounting holes
