Sensör Tipi : 1/3" progressive scan CMOS
Maksimum Çözünürlük : 2560 × 1440
Lens : Focal Length : 2.8 to 12 mm Aperture : F1.6 Focus : -I: Manual -IZ: Auto FOV Horizontal field of view: 98°to 28° Vertical field of view: 51°to 16° Diagonal field of view: 115°to 32°
Lens Montajı : ?14
Minumum Aydınlatma : Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON)
Objektif Hızı : -
Gece & Gündüz : IR cut filter
Dijital Gürültü Azaltma : 3D DNR
Geniş Dinamik Alan : 120 dB WDR
Video Sıkıştırma : Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG
Video Hızı : -
Resim Ayarları : Max. Resolution : 2560 × 1440 Main Stream : 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) Max. Frame Rate : 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) Sub-stream : 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) Max. Frame Rate : 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Image Enhancement : BLC, 3D DNR Image Setting : Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser Day/Night : Switch Auto, scheduled
Ağ Depolama Alanı : Support Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Tetikleyici : Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login
Portlar : 1 RJ45 10M/100M self-adaptive Ethernet port
Protokoller : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP
Standartlar : H.264 Type : Baseline Profile/Main Profile/High Profile H.264+ : Main stream supports H.265 Type : Main Profile H.265+ : Main stream supports Video Bit Rate : 32 Kbps to 8 Mbps
Gece Görü Mesafesi : -
Güç Gereksinimi : 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)
Ek Özellikler : Dimensions : Camera: ? 141 mm × 99.9 mm (5.6" × 3.9") With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1") Weight : Camera: approx. 820 g (1.8 lb.) With package: approx. 1200 g (2.6 lb.)
