İŞLEMCİ : Supports AMD® RYZEN series processors and 7th Gen A-series/ Athlon™ processors for Socket AM4
YONGA SETİ : AMD® X370 Chipset
BELLEK : • 4 x DDR4 memory slots, support up to 64GB - Supports DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/ 3200(OC)+ Mhz * • Dual channel memory architecture • Supports non-ECC UDIMM memory • Supports ECC UDIMM memory (non-ECC mode)
DAHİLİ GRAFİK : • 1 DVI-D port, supporting a maximum resolution of 1920x1200@60Hz, 1600x1200@60Hz* • 1 HDMI™ 1.4 port, supports a maximum resolution of 2560x1600@60Hz*
GENİŞLEME YUVALARI : • 2 x PCIe 3.0 x16 slots (PCIE_2, PCIE_4) - RYZEN series processors support x16/x0, x8/x8 mode - 7th Gen A-series/ Athlon™ processors support x8/x0 mode • 1 x PCIe 2.0 x16 slot (PCIE_6, supports x4 mode)* • 3 x PCIe 2.0 x1 slots
SES DESTEĞİ : • Realtek® ALC892 Codec - 7.1-Channel High Definition Audio
LAN : • 1 x Realtek® 8111H Gigabit LAN controller
USB PORTLARI : • ASMedia® ASM2142 Chipset - 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panel - 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel • AMD® X370 Chipset - 4 x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors - 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors) • AMD® CPU - 4 x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel
DEPOLAMA ARAYÜZÜ : • AMD® X370 Chipset • 6x SATA 6Gb/s ports • 1x M.2 slots (Key M) - Supports PCIe 3.0 x4 (RYZEN series processor) or PCIe 3.0 x2 (7th Gen A-series/ Athlon™ processors) and SATA 6Gb/s 2242/ 2260 /2280/ 22110 storage devices • Supports RAID 0, RAID 1 and RAID 10
ARKA GİRİŞ/ÇIKIŞ PORTLARI : - 1 x PS/2 keyboard/ mouse combo port - 2 x USB 2.0 Type-A ports - 1 x DVI-D port - 1 x HDMI™ 1.4 port - 1 x LAN (RJ45) port - 4 x USB 3.1 Gen1 Type-A ports - 1 x USB 3.1 Gen2 Type-A port - 1 x USB 3.1 Gen2 Type-C port - 6 x audio jacks
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : - 1 x 24-pin ATX 12V power connector - 1 x 8-pin ATX 12V power connector - 6 x SATA 6Gb/s connectors - 2 x USB 2.0 connectors (support additional 4 USB 2.0 ports) - 2 x USB 3.1 Gen1 connectors (support additional 4 USB 3.1 Gen1 ports) - 1 x 4-pin CPU fan connector - 1 x 4-pin PUMP fan connector (supports up to 2A) - 4 x 4-pin system fan connectors - 1 x RGB LED connector - 1 x TPM module connector - 1 x Serial port connector - 1 x Parallel port connector - 1 x Front panel audio connector - 2 x System panel connectors - 1 x Chassis Intrusion connector - 1 x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : -
FORM FAKTÖRÜ : • 12 in. x 9.6 in. (30.4 cm x 24.3 cm) • ATX Form Factor
BIOS : -
AÇIKLAMA : -
