İŞLEMCİ : Supports AMD Ryzen 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Processors for Socket AM4
YONGA SETİ : AMD A320 Chipset
BELLEK : 2 x DDR4 memory slots, support up to 32GB Supports DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/ 3200(OC)+ MHz1 Dual channel memory architecture Supports ECC UDIMM memory (non-ECC mode) Support non-ECC UDIMM memory
DAHİLİ GRAFİK : 1 x VGA port, supports a maximum resolution of 2048x1280@60Hz 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz 1 x HDMI 1.4 port, supporting a maximum resolution of 4096x2160@24Hz
GENİŞLEME YUVALARI : 1 x PCIe 3.0 x16 slot Supports x16 speed with AMD® Ryzen™ 1st and 2nd Generation processors Supports x8 speed with AMD® Ryzen™ with Radeon Vega Graphics and A-series/Athlon™X4 processors Supports x4 speed with AMD® Athlon™ with Radeon™ Vega Graphics Processors 2 x PCIe 2.0 x1 slots
SES DESTEĞİ : 7.1-Channel High Definition Audio
LAN : 1 x Realtek® 8111H Gigabit LAN controller
USB PORTLARI : 2 x USB 3.1 Gen1 (SuperSpeed USB) ports through the internal USB 3.1 Gen1 connector 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
DEPOLAMA ARAYÜZÜ : 4 x SATA 6Gb/s ports Supports RAID 0, RAID1 and RAID 10 1 x M.2 slot (Key M) Supports PCIe 3.0 x4 (RYZEN series processors) or PCIe 3.0 x2 (Athlon™ with Radeon™ Vega Graphics and A-series /Athlon™ X4 Processors) and SATA 6Gb/s Supports 2242/ 2260 /2280 storage devices
ARKA GİRİŞ/ÇIKIŞ PORTLARI : Mouse VGA Port USB 2.0 LAN Port HD Audio Connectors Keyboard DVI-D Port HDMI Port USB 3.1 Gen1
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Serial port connector 1 x LED strip connector 1 x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : Support for Windows® 10 64-bit Support for Windows® 7 64-bit To support Windows® 7 64-bit
FORM FAKTÖRÜ : m-ATX Form Factor
