İŞLEMCİ : Supports AMD® Ryzen 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors for Socket AM4
YONGA SETİ : AMD® B450 Chipset
BELLEK : 2 x DDR4 memory slots, support up to 32GB Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC) Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE) Dual channel memory architecture Supports non-ECC UDIMM memory Supports ECC UDIMM memory (non-ECC mode)
DAHİLİ GRAFİK : 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz 1 x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz
GENİŞLEME YUVALARI : 1 x PCIe 3.0 x16 slot(PCI_E1) Supports x16 speed with AMD® Ryzen™ 1st and 2nd Generation processors Supports x8 speed with AMD® Ryzen™ with Radeon Vega Graphics processors Supports x4 speed with AMD® Athlon™ with Radeon™ Vega Graphics Processors 2 x PCIe 2.0 x1 slots
SES DESTEĞİ : 7.1-Channel High Definition Audio
LAN : 1 x Realtek® 8111H Gigabit LAN controller
USB PORTLARI : AMD® B450 Chipset 4 x USB 3.1 Gen1 (SuperSpeed USB) ports through the internal USB 3.1 Gen1 connectors 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors) AMD® CPU 3 x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel 1 x USB 3.1 Gen1 (SuperSpeed USB) Type-C port on the back panel
DEPOLAMA ARAYÜZÜ : 4 x SATA 6Gb/s ports Supports RAID 0, RAID1 and RAID 10 1 x M.2 slot (Key M) Supports PCIe 3.0 x4 (AMD® Ryzen 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics) or PCIe 3.0 x2 (AMD® Athlon™ with Radeon™ Vega Graphics) and SATA 6Gb/s 2242/ 2260 /2280/ 22110 storage devices
ARKA GİRİŞ/ÇIKIŞ PORTLARI : PS/2 Combo Port LAN HD Audio Connectors Flash BIOS Button USB 2.0 DVI-D HDMI USB 3.1 Gen1
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 2 x USB 3.1 Gen1 connector (supports additional 4 USB 3.1 Gen1 ports) 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 1 x Front panel audio connector 2 x System panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Serial port connector 2 x 5050 RGB LED strip 12V connectors 1 x Clear CMOS jumper
İŞLETİM SİSTEMİ DESTEĞİ : Support for Windows® 10 64-bit Support for Windows® 7 64-bit
FORM FAKTÖRÜ : m-ATX Form Factor
BIOS : -
AÇIKLAMA : Boyut : 9.6 in. x 8.3 in. (24.4 cm x 21.0 cm)
