İŞLEMCİ : Supports 1st and 2nd Gen AMD® RYZEN™ THREADRIPPER™ Series Processors for SocketTR4
YONGA SETİ : AMD® X399 Chipset
BELLEK : 8 x DDR4 memory slots, support up to 128GB Supports DDR4 3600+(OC)/ 3466(OC)/ 3333(OC)/ 3200(OC)/ 3066(OC)/ 2933(OC)/ 2800(OC)/ 2667(OC)/ 2400/ 2133 MHz Quad channel memory architecture Supports ECC UDIMM memory
DAHİLİ GRAFİK : Yok
GENİŞLEME YUVALARI : 2x PCIe 3.0 x16 slots (PCIE_1, PCIE_4) 2x PCIe 3.0 x8 slots (PCIE_3, PCIE_5) 1x PCIE 2.0 x1 Slot
SES DESTEĞİ : 7.1-Channel High Definition Audio Supports S/PDIF output
LAN : 2 x Intel® I211AT Gigabit LAN controllers
USB PORTLARI : 1x USB 3.1 Gen1 (SuperSpeed USB) Type-A port on the back panel 1x USB 3.1 Gen1 (SuperSpeed USB) Type-C port on the back panel 4x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors 4x USB 2.0 (High-speed USB) ports available through the internal USB connectors
DEPOLAMA ARAYÜZÜ : AMD® X399 Chipset 8 x SATA 6Gb/s ports AMD® CPU 3 x M.2 ports (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s M2_1, M2_3 slots support 2242/ 2260 /2280 storage devices M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices
ARKA GİRİŞ/ÇIKIŞ PORTLARI : Clear CMOS Button USB 3.1 Gen1 Ports USB 3.1 Gen1 Ports Intel® WiFi/ Bluetooth Module Dual Intel® LAN Ports HD Audio Connectors Flash BIOS Button USB 3.1 Gen1 Ports AMD Turbo USB 3.1 Gen 1 Type A + C Optical S/PDIF-Out
DAHİLİ GİRİŞ/ÇIKIŞ PORTLARI : 1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connector 1x flat 4-pin ATX 12V power connector 8x SATA 6Gb/s connectors 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) 1x USB 3.1 Gen2 Type-C port 1x 4-pin CPU fan connector 1x 4-pin Water Pump connector 5x 4-pin system fan connectors 3x 4-pin extend fan connectors 2x Front panel connectors 1x Front panel audio connector 2x 5050 RGB LED strip 12V connector (JRGB1~2) 1x WS2812B Individually Addressable RGB LED strip 5V connector (JRAINBOW1) 1x CORSAIR connector (JCORSAIR1) 1x TPM module connector 3x 2-pin Thermal Sensors connectors
İŞLETİM SİSTEMİ DESTEĞİ : Support for Windows® 10 64-bit
FORM FAKTÖRÜ : E-ATX Form Factor
BIOS : -
AÇIKLAMA : Dimensions : 12 in. x 10.7 in. (30.4 cm x 27.2 cm)
