Assmann AB 814

Mouse emulation and keyboard emulation for automatic PC boot up. Three levels daisy chain cascadable for accessing up to 216 computers. Provides serial mouse and keyboard ports. Supports SVGA, VGA and Multisync monitors. Selects any computer by hot keys, buttons. Optional Foot Switch to select any computer. Built-in buzzer for switching confirmation. Keyboard LED status recorded and restored while switching among computers. Auto Scan for monitoring PC periodically PC Selection Keyboard / Button / Foot Switch Keyboard Emulation PS/2 and PC/AT Mouse Emulation Serial Mouse LEDs 6 Manual / 6 Port Status Video / VGA Band Width (-3db) MHz 100 MHz Max VGA Resolution / Vertical Freq. MHz 1024 x 768 / 80 Console Keyboard Connector 5-pin DIN Female Console Mouse Connector 9-pin D Type Male VGA Connector Port 15-pin HDB Type Male Enclosure Metal Weight 2800g or 7.5 pounds Dimensions (L x W x H) 254 x 180 x 82 (mm) Scan Interval 3, 10, 20, 40 seconds Optional Power Adapter 230AC, Europe Plug Standard Power Adapter 120AC, US standard
