Aten US3384I 8 x 4 USB 3.2 Gen 1 Sharing Switch

Allows sharing of up to 4 USB 3.2 devices among 8 PCs Bandwidth speed of 5 Gbps and backward compatibility with USB 2.0/1.1 to ensure swift data transmission Versatile port selection methods – front panel pushbutton, RS-232/RS-485 serial commands, and external remote port selector 1 Power on Detection – Automatically switches the PC focus to the last plugged-in/powered-on host device – Configurable priority port preference – allows the focus to switch to a secondary USB host when the primary one is lost Front panel port status LEDs – indicate which one of the PCs connected to the US3384i is having the focus at a glance Supports USB BC 1.2 to ensure sufficient power for downstream USB devices Overvoltage protection circuit – extends device lifespan and minimizes risks of electrical hazards/explosions led by voltage spikes surpassing safe operating limits Supports DC 9 – 24V power input through terminal block 2 Plug-and-play on Windows and macOS operating systems – no drivers are needed Hot-pluggable – users can connect/disconnect the host devices dynamically to the US3384i without powering off the switch Wall-mountable case constructed with premium metal for enhanced durability Note: 1. The remote port selector is sold separately, please contact your ATEN dealer for product information. 2. Supports either of the following power supplies: (1) DC terminal block (2) DC power jack (The power adapter (0AD8-8012-50M2) is sold separately, please contact your ATEN dealer for product information.) Computer Connections 8 Connectors Computer 8 x USB 3.2 Gen 1 Type-B Female (Blue) Device 4 x USB 3.2 Gen 1 Type-A Female (Blue) Serial 2 x 3-pin Terminal Block (Green) Power 1 x 2-pin 9-24V Terminal Block (Green) Power (Optional) 1 x 12V DC Jack Female (Black) Power Consumption DC12V:0.52W:130BTU/h DC24V:0.53W:130BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. Power Mode Terminal Block / DC Jack Power Adapter* *The power adapter (0AD8-8012-50M2) is sold separately, please contact your ATEN dealer for product information. Port Selection Pushbutton / Remote Port Selector* / Serial Command *The remote port selector (2XRT-0016G-1) is sold separately, please contact your ATEN dealer for product information. LEDs Selected 8 (Orange) Cable Length USB Cable 8 x USB 3.2 Gen 1 Type-A to Type-B Cables 1.2m Environmental Humidity 0-80% RH, Non-condensing Operating Temperature 0–50°C Storage Temperature -20–60°C Physical Properties Housing Metal Weight 0.50 kg ( 1.1 lb ) Dimensions (L x W x H) 20.00 x 8.06 x 2.50 cm (7.87 x 3.17 x 0.98 in.)
